Stroke Prediction Capstone

Source code: vnk8071/capstone_ml_engineer

Domain Background

According to the World Health Organization (WHO) stroke is the 2nd leading cause of death globally, responsible for approximately 11% of total deaths. It will be good if we detect and prevent this deadly disease in time, it will bring happiness to the sick and have more time to live.

Problem Statement

Currently, classification methods using machine learning and deep learning have become popular to assist doctors in diagnosing stroke and providing timely treatment. Here, we use two models of machine learning to predict stroke based on the input parameters like gender, age, various diseases, and smoking status. The challenge of working with imbalanced datasets is that most machine learning techniques will ignore, and in turn have poor performance on, the minority class, although typically it is performance on the minority class that is most important.

Installation

Create virtual environment

pip install -r requirements.txt

Install pre-commit hooks

make pre-commit-install

Dataset

In this project, we will use the dataset provided by Kaggle Activity dataset

This dataset is used to predict whether a patient is likely to get stroke based on the input parameters like gender, age, various diseases, and smoking status. Each row in the data provides relavant information about the patient.

#	Feature	Description
1	id	unique identifier
2	gender	"Male", "Female" or "Other"
3	age	age of the patient
4	hypertension	0 if the patient doesn't have hypertension, 1 if the patient has hypertension
5	heart_disease	n0 if the patient doesn't have any heart diseases, 1 if the patient has a heart disease
6	ever_married	"No" or "Yes"
7	work_type	"children", "Govt_jov", "Never_worked", "Private" or "Self-employed"
8	Residence_type	"Rural" or "Urban"
9	avg_glucose_level	average glucose level in blood
10	bmi	body mass index
11	smoking_status	"formerly smoked", "never smoked", "smokes" or "Unknown"*
12	stroke	1 if the patient had a stroke or 0 if not

EDA

Details in explore_data_analysis/EDA.ipynb

Check type each column of dataset

RangeIndex: 5110 entries, 0 to 5109
Data columns (total 12 columns):
 #   Column             Non-Null Count  Dtype
---  ------             --------------  -----
 id                 5110 non-null   int64
 gender             5110 non-null   object
 age                5110 non-null   float64
 hypertension       5110 non-null   int64
 heart_disease      5110 non-null   int64
 ever_married       5110 non-null   object
 work_type          5110 non-null   object
 Residence_type     5110 non-null   object
 avg_glucose_level  5110 non-null   float64
 bmi                4909 non-null   float64
smoking_status     5110 non-null   object
stroke             5110 non-null   int64
dtypes: float64(3), int64(4), object(5)

Check missing values

id                     0
gender                 0
age                    0
hypertension           0
heart_disease          0
ever_married           0
work_type              0
Residence_type         0
avg_glucose_level      0
bmi                  201
smoking_status         0
stroke                 0
dtype: int64

The dataset is imbalanced, with only 4.9% of the rows belonging to the positive class.

plot_stroke

Histogram of numeric columns

plot_hist -> bmi and avg_glucose_level are skewed -> age is normal distribution

Value counts of category columns

plot_work_type

-> Stroke patients are mostly private workers

plot_smoking_status

-> Stroke patients are equally distributed in smoking status

Correlation with binary columns

plot_heart_disease

plot_residence_type

plot_hypertension

Correlation matrix

correlation

Data Preprocessing

Details in extract_transform_load/pipeline.py

Extract

Read csv file
Extract metadata

2023-09-23 20:20:44,678 - extract_transform_load.extract - INFO - Metadata: {'file_path': 'data/healthcare-dataset-stroke-data.csv', 'shape': (5110, 12), 'columns': ['id', 'gender', 'age', 'hypertension', 'heart_disease', 'ever_married', 'work_type', 'Residence_type', 'avg_glucose_level', 'bmi', 'smoking_status', 'stroke'], 'dtypes': {'id': dtype('int64'), 'gender': dtype('O'), 'age': dtype('float64'), 'hypertension': dtype('int64'), 'heart_disease': dtype('int64'), 'ever_married': dtype('O'), 'work_type': dtype('O'), 'Residence_type': dtype('O'), 'avg_glucose_level': dtype('float64'), 'bmi': dtype('float64'), 'smoking_status': dtype('O'), 'stroke': dtype('int64')}, 'category_columns': [], 'numeric_columns': ['id', 'age', 'hypertension', 'heart_disease', 'avg_glucose_level', 'bmi', 'stroke']}

Transform

Fill missing values in bmi column with mean
Drop rows with Other in gender column
Drop id column
Reformatting type of age column to int64

Load

Strategy: split stroke data into train and test sets with test size of 0.2 and split non-stroke data into train and test sets with test size of 0.05
Save train and test sets to csv files

test_strategy

The current ratio of stroke is 17.06% in test set

Feature Engineering

Details in feature_engineering/pipeline.py

Standardlize

Label encoding for category columns
Standardizing numeric columns

2023-09-23 20:24:30,992 - feature_engineering.standardlize - INFO - Standardizing ['age', 'hypertension', 'heart_disease', 'avg_glucose_level', 'bmi']
2023-09-23 20:24:31,001 - feature_engineering.standardlize - INFO - Label encoding ['gender', 'ever_married', 'work_type', 'Residence_type', 'smoking_status']
2023-09-23 20:24:31,076 - feature_engineering.standardlize - INFO - Standardizing ['age', 'hypertension', 'heart_disease', 'avg_glucose_level', 'bmi']
2023-09-23 20:24:31,087 - feature_engineering.standardlize - INFO - Label encoding ['gender', 'ever_married', 'work_type', 'Residence_type', 'smoking_status']

SMOTE

Balancing data with target class stroke in train set

smote

Feature Selection

from sklearn.feature_selection import RFE
selected_feature_count = int(
    np.round(0.6 * df_train.shape[1])
)
rfe = RFE(
    estimator=RandomForestClassifier(random_state=random_state),
    n_features_to_select=selected_feature_count,
)

Result

2023-09-23 20:24:35,801 - feature_engineering.feature_selection - INFO - 7 important features
2023-09-23 20:24:35,801 - feature_engineering.feature_selection - INFO - Index(['gender', 'age', 'hypertension', 'work_type', 'avg_glucose_level',
       'bmi', 'smoking_status'],
      dtype='object')
2023-09-23 20:24:35,885 - feature_engineering.feature_selection - INFO - Saved data/df_train_feature_engineering_smote_selection.csv and data/df_test_feature_engineering_selection.csv
2023-09-23 20:24:35,888 - __main__ - INFO - Pipeline completed

Hyperparameter Tuning

Using SageMaker Hyperparameter Tuning to find best hyperparameters for Random Forest model rf-hp-tuning

Details in training/sagemaker-hyperparameter-tuning.ipynb

Model Training

Logistic Regression

from sklearn.linear_model import LogisticRegression

model = LogisticRegression(
    random_state=args.random_state,
    penalty=args.penalty,
    C=1.0,
    solver=args.solver,
    max_iter=args.max_iter,
)

Result

2023-09-23 20:58:28,721 - __main__ - INFO - Running k-fold cross-validation
2023-09-23 20:58:28,756 - __main__ - INFO - Fold 1: Accuracy=79.805% | F1-score=80.296% | AUC=0.798
2023-09-23 20:58:28,786 - __main__ - INFO - Fold 2: Accuracy=79.372% | F1-score=80.330% | AUC=0.793
2023-09-23 20:58:28,815 - __main__ - INFO - Fold 3: Accuracy=78.506% | F1-score=79.377% | AUC=0.786
2023-09-23 20:58:28,848 - __main__ - INFO - Fold 4: Accuracy=78.831% | F1-score=79.497% | AUC=0.789
2023-09-23 20:58:28,876 - __main__ - INFO - Fold 5: Accuracy=78.873% | F1-score=79.938% | AUC=0.788
2023-09-23 20:58:28,877 - __main__ - INFO - CV Accuracy: Mean 79.077% & STD 0.457%
2023-09-23 20:58:28,877 - __main__ - INFO - CV F1-score: Mean 79.888% & STD  0.395%
2023-09-23 20:58:28,877 - __main__ - INFO - CV AUC: Mean 0.791 & STD  0.005
2023-09-23 20:58:28,910 - __main__ - INFO - test set - Accuracy : 78.840%
2023-09-23 20:58:28,910 - __main__ - INFO - test set - F1-score : 56.338%
2023-09-23 20:58:28,910 - __main__ - INFO - test set - AUC: 0.793
2023-09-23 20:58:28,918 - __main__ - INFO - Classification_report
              precision    recall  f1-score   support

           0       0.95      0.79      0.86       243
           1       0.43      0.80      0.56        50

    accuracy                           0.79       293
   macro avg       0.69      0.79      0.71       293
weighted avg       0.86      0.79      0.81       293
2023-09-23 20:58:28,919 - __main__ - INFO - Confusion matrix:
[[191  52]
 [ 10  40]]

Random Forest

from sklearn.ensemble import RandomForestClassifier

model = RandomForestClassifier(
    random_state=args.random_state,
    n_estimators=args.n_estimators,
    max_depth=args.max_depth,
    min_samples_split=args.min_samples_split,
)

Result

2023-09-23 21:06:09,088 - __main__ - INFO - Running k-fold cross-validation
2023-09-23 21:06:10,716 - __main__ - INFO - Fold 1: Accuracy=89.009% | F1-score=89.288% | AUC=0.891
2023-09-23 21:06:12,276 - __main__ - INFO - Fold 2: Accuracy=88.630% | F1-score=89.186% | AUC=0.886
2023-09-23 21:06:13,821 - __main__ - INFO - Fold 3: Accuracy=89.117% | F1-score=89.404% | AUC=0.891
2023-09-23 21:06:15,407 - __main__ - INFO - Fold 4: Accuracy=88.468% | F1-score=88.900% | AUC=0.885
2023-09-23 21:06:16,963 - __main__ - INFO - Fold 5: Accuracy=89.382% | F1-score=89.738% | AUC=0.894
2023-09-23 21:06:16,964 - __main__ - INFO - CV Accuracy: Mean 88.921% & STD 0.331%
2023-09-23 21:06:16,964 - __main__ - INFO - CV F1-score: Mean 89.303% & STD  0.274%
2023-09-23 21:06:16,964 - __main__ - INFO - CV AUC: Mean 0.889 & STD  0.003
2023-09-23 21:06:18,885 - __main__ - INFO - test set - Accuracy : 78.157%
2023-09-23 21:06:18,885 - __main__ - INFO - test set - F1-score : 54.286%
2023-09-23 21:06:18,885 - __main__ - INFO - test set - AUC: 0.773
2023-09-23 21:06:18,891 - __main__ - INFO - Classification_report
              precision    recall  f1-score   support

           0       0.94      0.79      0.86       243
           1       0.42      0.76      0.54        50

    accuracy                           0.78       293
   macro avg       0.68      0.77      0.70       293
weighted avg       0.85      0.78      0.80       293

2023-09-23 21:06:18,892 - __main__ - INFO - Confusion matrix:
[[191  52]
 [ 12  38]]

LightGBM

from lightgbm import LGBMClassifier

model = LGBMClassifier(
        random_state=args.random_state,
        n_estimators=args.n_estimators,
        max_depth=args.max_depth,
        learning_rate=args.learning_rate,
    )

Result

2023-09-23 21:13:11,054 - __main__ - INFO - Running k-fold cross-validation
2023-09-23 21:13:11,617 - __main__ - INFO - Fold 1: Accuracy=89.875% | F1-score=90.090% | AUC=0.899
2023-09-23 21:13:12,034 - __main__ - INFO - Fold 2: Accuracy=89.659% | F1-score=90.280% | AUC=0.896
2023-09-23 21:13:12,477 - __main__ - INFO - Fold 3: Accuracy=88.901% | F1-score=89.250% | AUC=0.889
2023-09-23 21:13:12,989 - __main__ - INFO - Fold 4: Accuracy=89.063% | F1-score=89.555% | AUC=0.891
2023-09-23 21:13:13,926 - __main__ - INFO - Fold 5: Accuracy=89.328% | F1-score=89.659% | AUC=0.893
2023-09-23 21:13:13,926 - __main__ - INFO - CV Accuracy: Mean 89.365% & STD 0.362%
2023-09-23 21:13:13,927 - __main__ - INFO - CV F1-score: Mean 89.767% & STD  0.372%
2023-09-23 21:13:13,927 - __main__ - INFO - CV AUC: Mean 0.894 & STD  0.003
2023-09-23 21:13:14,593 - __main__ - INFO - test set - Accuracy : 70.990%
2023-09-23 21:13:14,593 - __main__ - INFO - test set - F1-score : 48.485%
2023-09-23 21:13:14,593 - __main__ - INFO - test set - AUC: 0.746
2023-09-23 21:13:14,602 - __main__ - INFO - Classification_report
              precision    recall  f1-score   support

           0       0.94      0.69      0.80       243
           1       0.35      0.80      0.48        50

    accuracy                           0.71       293
   macro avg       0.65      0.75      0.64       293
weighted avg       0.84      0.71      0.74       293

2023-09-23 21:13:14,603 - __main__ - INFO - Confusion matrix:
[[168  75]
 [ 10  40]]

XGBoost

from xgboost import XGBClassifier

model = XGBClassifier(
    random_state=args.random_state,
    n_estimators=args.n_estimators,
    max_depth=args.max_depth,
    learning_rate=args.learning_rate,
)

Result

2023-09-23 21:16:21,089 - __main__ - INFO - Running k-fold cross-validation
2023-09-23 21:16:21,398 - __main__ - INFO - Fold 1: Accuracy=89.063% | F1-score=89.357% | AUC=0.891
2023-09-23 21:16:21,704 - __main__ - INFO - Fold 2: Accuracy=89.767% | F1-score=90.362% | AUC=0.897
2023-09-23 21:16:22,002 - __main__ - INFO - Fold 3: Accuracy=88.738% | F1-score=89.178% | AUC=0.888
2023-09-23 21:16:22,296 - __main__ - INFO - Fold 4: Accuracy=88.684% | F1-score=89.243% | AUC=0.887
2023-09-23 21:16:22,589 - __main__ - INFO - Fold 5: Accuracy=88.732% | F1-score=89.189% | AUC=0.887
2023-09-23 21:16:22,589 - __main__ - INFO - CV Accuracy: Mean 88.997% & STD 0.408%
2023-09-23 21:16:22,590 - __main__ - INFO - CV F1-score: Mean 89.466% & STD  0.453%
2023-09-23 21:16:22,590 - __main__ - INFO - CV AUC: Mean 0.890 & STD  0.004
2023-09-23 21:16:22,943 - __main__ - INFO - test set - Accuracy : 72.355%
2023-09-23 21:16:22,943 - __main__ - INFO - test set - F1-score : 50.909%
2023-09-23 21:16:22,943 - __main__ - INFO - test set - AUC: 0.770
2023-09-23 21:16:22,950 - __main__ - INFO - Classification_report
              precision    recall  f1-score   support

           0       0.96      0.70      0.81       243
           1       0.37      0.84      0.51        50

    accuracy                           0.72       293
   macro avg       0.66      0.77      0.66       293
weighted avg       0.85      0.72      0.76       293

2023-09-23 21:16:22,952 - __main__ - INFO - Confusion matrix:
[[170  73]
 [  8  42]]

Evaluation metrics

Confusion matrix with raw data

confusion_matrix

Confusion matrix with feature engineering + SMOTE + feature selection

confusion_matrix

Accuracy-F1-AUC

evaluation_metrics

Explanation:

With raw data, the model is overfitting and skewed to negative class (not stroke) and get the same result (accuracy, F1 score, AUC) with benchmark models.
With feature engineering, the model is not overfitting and can learn with positive class (stroke) and get better result in F1 score and AUC than benchmark models, however the accuracy is lower than their benchmark because we get better accuracy in positive class and lower in negative class.
In hyperparameter tuning, we can see that the Random Forest model increase the result than default hyperparameter.
We just have 293 rows in test set, so the result is not stable, we need more data to get better result. We can see that the result of Logistic Regression model is better than other models, but in production with large data, I think we will choose Random Forest model to deploy.

API

Using FastAPI to create API for inference.

Details in api/inference.py request_ui

Test API

Using pytest to test API.

Details in tests/test_api.py

test_api

Conclusion

The dataset is imbalanced, with only 4.9% of the rows belonging to the positive class.
The benchmark model is a logistic regression model with the default hyperparameter which has the accuracy between 70 and 80%.
With feature engineering, the model is not overfitting and can learn with positive class (stroke) and get better result in F1 score and AUC than benchmark models, however the accuracy is lower than their benchmark because we get better accuracy in positive class and lower in negative class.
In hyperparameter tuning, we can see that the Random Forest model increase the result than default hyperparameter.
We just have 293 rows in test set, so the result is not stable, we need more data to get better result. We can see that the result of Logistic Regression model is better than other models, but in production with large data, I think we will choose Random Forest model to deploy.

Future work

Get more data
Try other models
Try other hyperparameters
Try other feature selection methods
Try other data augmentation methods
Try other metrics
Try training in SageMaker and deploy to SageMaker endpoint

Stroke Prediction Capstone

Domain Background​

Problem Statement​

Installation​

Create virtual environment​

Install pre-commit hooks​

Dataset​

EDA​

Data Preprocessing​

Extract​

Transform​

Load​

Feature Engineering​

Standardlize​

SMOTE​

Feature Selection​

Hyperparameter Tuning​

Model Training​

Logistic Regression​

Random Forest​

LightGBM​

XGBoost​

Evaluation metrics​

API​

Test API​

Conclusion​

Future work​

Domain Background

Problem Statement

Installation

Create virtual environment

Install pre-commit hooks

Dataset

EDA

Data Preprocessing

Extract

Transform

Load

Feature Engineering

Standardlize

SMOTE

Feature Selection

Hyperparameter Tuning

Model Training

Logistic Regression

Random Forest

LightGBM

XGBoost

Evaluation metrics

API

Test API

Conclusion

Future work
